One Head Woodworking CNC Machine Taiwan TBI Ball Screw Cnc Engraving Equipment

One Head Woodworking CNC Machine Taiwan TBI Ball Screw Cnc Engraving Equipment

One Head Woodworking CNC Machine Taiwan TBI Ball Screw Cnc Engraving Equipment

Product Details:

Place of Origin: Shandong, China (Mainland)
Brand Name: BL
Certification: CE ISO
Model Number: AM1325

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set/Sets
Price: Negotiable
Packaging Details: Carton Box
Delivery Time: Shipped in 30 working days after payment
Payment Terms: T/T or L/C
Supply Ability: 30 Sets per Month
Contact Now
Detailed Product Description
CNC: CNC Wood Engraving Machine Voltage: AC380V/50HZ
Power(W): 4.5KW Dimension(L*W*H): 1300*2500*200mm
Weight: 1500kg Control System: Taiwan Syntec Control System
Working Area: 1300x2500mm Product Name: One Head Wood Cnc 1325 Carving Machine Manufacturer
Application: Wood Working Transmission: Taiwan TBI Ball Screw
Motor: Servo Motor Spindle: ITALY HSD Air Cooling Spindle
Software: Ucancam / ArtCam/TYPE3



One Head Woodworking CNC Machine Taiwan TBI Ball Screw Cnc Engraving Equipment





This machine is a professional CNC wood working machine.Whole body with steel structure, dual motor drive,high speed.High loading capacity, smooth operation.Imported ball screw linear guide rail , accurate engraving.Optional spindle are imported NSK bearing,high speed 3 KW water cooling spindle with stable performance.Max rapid travel rate can reach 25m/min and it can be increased with the vigorous cutting spindle.





CNC wood engraving machine Description


1. CNC wood engraving machine Application range:

Furniture Industry: They can be used to engrave panel furniture,office furniture ,customized furniture,Cabinets, wardrobes, wooden doors, bedside table  solid Wood doors,Cupboard doors, interior doors, sofa legs, headboards,  and other panel furniture.
Wooden product industry:They can be used to engrave musical instrument,Audio,game cabinet,computer desk etc

Panel board processing Industry:They can be used for Insulation parts ,plastic board,PCB, Inner body of High-speed train, Anti-folding board,Epoxy Resin ,ABS,PP/PE etc



2. CNC wood engraving machine Features

A. The machine used for panel furniture and board cabinet processing ,widely used in cutting ,drilling ,sloting ,milling etc .

B. Heavy stell structure body to keep machine strong for heavy cutting working .

C. Automatic oil lubrication system to keep machine long time working and using life .

D. Machine have self-protect design ,Only cycline closer the machine can working


CNC wood engraving machine Specifications




X/Y/Z working area

1300*2500*200mm /1220*2440*200mm

reposition accuracy

0.05mm

spindle power

4.5kw,6kw,9kw  air cooling spindle (optional)

spindle speed

0-18000rpm/min or 0-24000rpm/m

driver motor

 servo motor

machine structure

welded structure

X/Y structure

rack and pinion,taiwan HIWIN square rail

Z structure

taiwan TBI ball screw

table structure

vacuum table

max.travelling speed

50000mm/min

max.working speed

25000mm/min

command code

HPGL/G code

working voltage

AC 380V/50HZ

Operating system

syntec control system
